RCCN Solid Wiring Duct

  RCCN Solid Wiring Duct

RCCN Solid Wiring Duct

Solid wall design fully encloses cables providing maximum protection and aesthetics
Certificates:UL:E306674 CE:EN50085 RoHS,REACH。
Made of rigid PVC
UL Recognized continuous use temperature: 50°C (122°F)
UL94 Flammability Rating of V-0
Supplied without mounting holes
Available color:gray.white.blue.black and other special colors
Work Temperature:-40°C to 65°C
     RCCN Solid Wiring Duct





Item No.

W*H

    Wire
capability
/2.0sp

Pack/M
Gray White Blue Black
SDR1616 SDR1616W SDR1616E SDR1616B 16*16 3~10pcs 300M
SDR2516 SDR2516W SDR2516E SDR2516B 25*16 5~15pcs 240M
SDR4016 SDR4016W SDR4016E SDR4016B 40*16 15~30pcs 200M
SDR1520 SDR1520W SDR1520E SDR1520B 15*20 8~12pcs 260M
SDR2020 SDR2020W SDR2020E SDR2020B 20*20 10~20pcs 240M
SDR4020 SDR4020W SDR4020E SDR4020B 40*20 15~25pcs 140M
SDR1525 SDR1525W SDR1525E SDR1525B 15*25 5~15pcs 260M
SDR2025 SDR2025W SDR2025E SDR2025B 20*25 5~15pcs 200M
SDR2525 SDR2525W SDR2525E SDR2525B 25*25 10~25pcs 200M
SDR3025 SDR3025W SDR3025E SDR3025B 30*25 12~28pcs 160M
SDR4025 SDR4025W SDR4025E SDR4025B 40*25 20~25pcs 120M
SDR5025 SDR5025W SDR5025E SDR5025B 50*25 20~25pcs 100M
SDR1530 SDR1530W SDR1530E SDR1530B 15*30 8~15pcs 200M
SDR2030 SDR2030W SDR2030E SDR2030B 20*30 25~35pcs 180M
SDR2530 SDR2530W SDR2530E SDR2530B 25*30 25~35pcs 160M
SDR3030 SDR3030W SDR3030E SDR3030B 30*30 25~35pcs 140M
SDR4030 SDR4030W SDR4030E SDR4030B 40*30 30~40pcs 100M
SDR2233 SDR2233W SDR2233E SDR2233B 22*33 15~25pcs 180M
SDR3333 SDR3333W SDR3333E SDR3333B 33*33 30~40pcs 160M
SDR2035 SDR2035W SDR2035E SDR2035B 20*35 30~40pcs 100M
SDR3535 SDR3535W SDR3535E SDR3535B 35*35 35~45pcs 112M
SDR5035 SDR5035W SDR5035E SDR5035B 50*35 40~60pcs 88M
SDR2040 SDR2040W SDR2040E SDR2040B 20*40 20~25pcs 110M
SDR2540 SDR2540W SDR2540E SDR2540B 25*40 20~25pcs 112M
SDR4040 SDR4040W SDR4040E SDR4040B 40*40 60~70pcs 100M
SDR6040 SDR6040W SDR6040E SDR6040B 60*40 100~115pcs 68M
SDR8040 SDR8040W SDR8040E SDR8040B 80*40 120~135pcs 48M
SDR10040 SDR10040W SDR10040E SDR10040B 100*40 120~135pcs 32M
SDR2545 SDR2545W SDR2545E SDR2545B 25*45 20~25pcs

104M
SDR3345 SDR3345W SDR3345E SDR3345B 33*45 40~55pcs 108M
SDR4545 SDR4545W SDR4545E SDR4545B 45*45 60~70pcs 72M
SDR6545 SDR6545W SDR6545E SDR6545B 65*45 110~120pcs 56M
SDR2050 SDR2050W SDR2050E SDR2050B 20*50 20~30pcs 100M
SDR2550 SDR2550W SDR2550E SDR2550B 25*50 20~30pcs 100M
SDR3050 SDR3050W SDR3050E SDR3050B 30*50 25~40pcs 84M
SDR3550 SDR3550W SDR3550E SDR3550B 35*50 40~60pcs 80M
SDR4050 SDR4050W SDR4050E SDR4050B 40*50 60~70pcs 68M
SDR4550 SDR4550W SDR4550E SDR4550B 45*50 70~80pcs 60M
SDR5050 SDR5050W SDR5050E SDR5050B 50*50 80~90pcs 60M
SDR5550 SDR5550W SDR5550E SDR5550B 55*50 85~95pcs 50M
SDR6050 SDR6050W SDR6050E SDR6050B 60*50 100~120pcs 48M
SDR8050 SDR8050W SDR8050E SDR8050B 80*50 160~180pcs 40M
SDR10050 SDR10050W SDR10050E SDR10050B 100*50 200~250pcs 26M
SDR12555 SDR12555W SDR12555E SDR12555B 125*55 220~270pcs 20M
SDR2060 SDR2060W SDR2060E SDR2060B 20*60 5~45pcs 100M
SDR2560 SDR2560W SDR2560E SDR2560B 25*60 40~50pcs 100M
SDR3060 SDR3060W SDR3060E SDR3060B 30*60 60~80pcs 80M
SDR3560 SDR3560W SDR3560E SDR3560B 35*60 65~85pcs 70M
SDR4060 SDR4060W SDR4060E SDR4060B 40*60 100~115pcs 60M
SDR4560 SDR4560W SDR4560E SDR4560B 45*60 110~125pcs 30M
SDR5060 SDR5060W SDR5060E SDR5060B 50*60 120~135pcs 60M
SDR6060 SDR6060W SDR6060E SDR6060B 60*60 120~135pcs 48M
SDR8060 SDR8060W SDR8060E SDR8060B 80*60 180~210pcs 36M
SDR10060 SDR10060W SDR10060E SDR10060B 100*60 240~290pcs 28M
SDR11060 SDR11060W SDR11060E SDR11060B 110*60 250~300pcs 48M
SDR12060 SDR12060W SDR12060E SDR12060B 120*60 260~320pcs 48M
SDR15060 SDR15060W SDR15060E SDR15060B 150*60 300~360pcs 16M
SDR2565 SDR2565W SDR2565E SDR2565B 25*65 40~50pcs 88M
SDR3365 SDR3365W SDR3365E SDR3365B 33*65 40~70pcs 80M
SDR4565 SDR4565W SDR4565E SDR4565B 45*65 110~120pcs 52M
SDR6565 SDR6565W SDR6565E SDR6565B 65*65 180~200pcs 44M
SDR7265 SDR7265W SDR7265E SDR7265B 72*65 190~210pcs 40M
SDR5075 SDR5075W SDR5075E SDR5075B 50*75 180~210pcs 32M
SDR7575 SDR7575W SDR7575E SDR7575B 75*75 200~240pcs 24M
SDR2580 SDR2580W SDR2580E SDR2580B 25*80 100~120pcs 72M
SDR3080 SDR3080W SDR3080E SDR3080B 30*80 110~125pcs 56M
SDR3580 SDR3580W SDR3580E SDR3580B 35*80 110~130pcs 56M
SDR4080 SDR4080W SDR4080E SDR4080B 40*80 140~160pcs 48M
SDR4580 SDR4580W SDR4580E SDR4580B 45*80 140~160pcs 40M
SDR5080 SDR5080W SDR5080E SDR5080B 50*80 160~180pcs 40M
SDR5580 SDR5580W SDR5580E SDR5580B 55*80 160~180pcs 32M
SDR6080 SDR6080W SDR6080E SDR6080B 60*80 180~210pcs 32M
SDR8080 SDR8080W SDR8080E SDR8080B 80*80 240~290pcs 24M
SDR10080 SDR10080W SDR10080E SDR10080B 100*80 260~350pcs 24M
SDR12080 SDR12080W SDR12080E SDR12080B 120*80 280~380pcs 16M
SDR14080 SDR14080W SDR14080E SDR14080B 140*80 350~450pcs 16M
SDR25100 SDR25100W SDR25100E SDR25100B 25*100 110~160pcs 60M
SDR33100 SDR33100W SDR33100E SDR33100B 33*100 130~165pcs 44M
SDR40100 SDR40100W SDR40100E SDR40100B 40*100 130~175pcs 40M
SDR50100 SDR50100W SDR50100E SDR50100B 50*100 220~250pcs 40M
SDR60100 SDR60100W SDR60100E SDR60100B 60*100 240~290pcs 32M
SDR70100 SDR70100W SDR70100E SDR70100B 70*100 240~290pcs 32M
SDR75100 SDR75100W SDR75100E SDR75100B 75*100 260~350pcs 24M
SDR80100 SDR80100W SDR80100E SDR80100B 80*100 260~350pcs 24M
SDR100100 SDR100100W SDR100100E SDR100100B 100*100 300~400pcs 24M
SDR120100 SDR120100W SDR120100E SDR120100B 120*100 350~450pcs 16M
SDR150100 SDR150100W SDR150100E SDR150100B 150*100 400~650pcs 16M
SDR100130 SDR100130W SDR100130E SDR100130B 100*130 350~450pcs 16M
*SDR200100 SDR200100W SDR200100E SDR200100B 200*100 600~800pcs 12M
*SDR200150 SDR200150W SDR200150E SDR200150B 200*150 900~1200pcs 10M






RCCN Solid Wiring Duct



RCCN Solid Wiring Duct



RCCN Solid Wiring Duct



RCCN Solid Wiring Duct






RCCN  Din Rails



RCCN Solid Wiring Duct        RCCN Solid Wiring Duct


RCCN Solid Wiring Duct

RCCN Solid Wiring Duct



Material:high quality and strength cold rolled steel with electroplate
EN50022 Product standard: EN50022
Color: yellow plated nickle,silver plated zinc
Operated temperature:-40°C standing heat to 100°C
Use way: fixed on the panel then installed with electric parts
Features: perfect design,with huge pressure,exactly dia., rust resistant
Special length or special hole come with MOQ., Rohs approved products are available.
TS-35/7.5/1/1M/R Environment-friendly goods’ part no.:TS-35/7.5/1/1M/ROHS





Item No.
Outer width/Outer height/
Thickness/Length 		 Material Length
per pcs		 Packing/
carton
TS-35/7.5   Series
TS-35/7.5/1.0/1M Color zinc steel 1M 50M
TS-35/7.5/1.0/1M-ROHS ROHS silver zinc plated steel 1M 50M
TS-35/7.5/1.0/2M Color zinc steel 2M 100M
TS-35/7.5/1.0/2M-ROHS ROHS silver zinc plated steel 2M 100M
TS-35/15  Series
TS-35/15/1.5/1M Color zinc steel 1M 30M
TS-35/15/1.5/1M-ROHS ROHS silver zinc plated steel 1M 30M
TS-35/15/1.5/2M Color zinc steel 2M 60M
TS-35/15/1.5/2M-ROHS ROHS silver zinc plated steel 2M 60M
LSC-35/7.5/1.1  Series
LSC-35/7.5/1.1/1M ROHS Aluminum metal 1M 100M
LSC-35/7.5/1.1/2M ROHS Aluminum metal 2M 100M
LSC-35/7.5/1.1/1M-No bottom ROHS Aluminum metal 1M 100M
LSC-35/7.5/1.1/2M-No bottom ROHS Aluminum metal 2M 100M
LS-35/7.5/1.5 Series
LS-35/7.5/1.5/1M ROHS Aluminum metal 1M 100M
LS-35/7.5/1.5/2M ROHS Aluminum metal 2M 100M
LS-35/7.5/1.5/1M-No bottom ROHS Aluminum metal 1M 100M
LS-35/7.5/1.5/2M-No bottom ROHS Aluminum metal 2M 100M
