Note:installed by crimp tool YYT-1
|
Insulated square：0.5～1.5mm2(AWG22～16) Max. cunrrent：lmax＝10A color:red
| Item No. |
NEMA-TAB
T*B1 |
DIMENSION |
| B |
Dφ |
dφ |
L |
F |
H |
| mm |
mm |
mm |
mm |
mm |
mm |
mm |
| PV 1.25-187(5) |
0.5×4.75 |
5.6 |
3.8 |
1.7 |
20.0 |
6.0 |
10 |
| PV 1.25-187(8) |
0.8×4.75 |
5.6 |
3.8 |
1.7 |
20.0 |
6.0 |
10 |
| PV 1.25-250 |
0.8×6.35 |
7.4 |
3.8 |
1.7 |
23.2 |
7.8 |
10 |
Insulated square：1.5～2.5mm2(AWG16～14) Max. cunrrent：lmax＝15A color:blue
| Item No. |
NEMA-TAB
T*B1 |
DIMENSION |
| B |
Dφ |
dφ |
L |
F |
H |
| mm |
mm |
mm |
mm |
mm |
mm |
mm |
| PV 2-187(5) |
0.5×4.75 |
5.6 |
4.0 |
2.3 |
20.0 |
6.0 |
10 |
| PV 2-187(8) |
0.8×4.75 |
5.6 |
4.0 |
2.3 |
20.0 |
6.0 |
10 |
| PV 2-250 |
0.8×6.35 |
7.4 |
4.0 |
2.3 |
23.5 |
7.8 |
10 |
Insulated square：4～6mm2(AWG12～10) Max. cunrrent：lmax＝24A color:yellow
| Item No. |
NEMA-TAB
T*B1 |
DIMENSION |
| B |
Dφ |
dφ |
L |
F |
H |
| mm |
mm |
mm |
mm |
mm |
mm |
mm |
| PV 5.5-250 |
0.8×6.35 |
7.4 |
5.7 |
3.4 |
23.5 |
7.8 |
13 |
