Cable size: 0.5～1.5mm2（A.W.G.22～16) max current:Imax=19A material:purple copper thickness:0.75mm
|
Item No
|
Dimension
|
|
USA screw
|
Screw dia.d2
|
B |
L |
F |
E |
Dφ |
dφ |
| mm |
mm |
mm |
mm |
mm |
mm |
mm |
| Y 1.25－3 |
#4 |
3.2mm |
5.7 |
16.0 |
6.5 |
4.8 |
3.4 |
1.7 |
| YS 1.25－3.5 |
#6 |
3.7mm |
5.7 |
16.0 |
6.5 |
| YL 1.25-3.5 |
#6 |
3.7mm |
6.4 |
16.0 |
6.5 |
| YS 1.25-4 |
#8 |
4.3mm |
6.4 |
16.0 |
6.5 |
| YM 1.25-4 |
#8 |
4.3mm |
7.2 |
16.0 |
6.5 |
| YL 1.25-4 |
#8 |
4.3mm |
8.1 |
16.0 |
6.5 |
| YS 1.25-5 |
#10 |
5.3mm |
8.1 |
16.0 |
6.5 |
| YL 1.25-5 |
#10 |
5.3mm |
9.5 |
16.0 |
6.5 |
| YS 1.25-6 |
1/4 |
6.5mm |
9.5 |
16.0 |
6.5 |
| YL 1.25-6 |
1/4 |
6.5mm |
12.0 |
22.0 |
11.0 |
Cable size: 1.5～2.5mm2（A.W.G.16～14) max current:Imax=27A material:purple copper thickness:0.8mm
|
Item No
|
Dimension
|
|
USA screw
|
Screw dia.d2
|
B |
L |
F |
E |
D |
dφ |
| mm |
mm |
mm |
mm |
mm |
mm |
mm |
|
Y 2－3
|
#4 |
3.2mm |
5.7 |
16.0 |
6.5 |
4.8 |
4.1 |
2.3 |
| YS 2－3.5 |
#6 |
3.7mm |
5.7 |
16.0 |
6.5 |
| YL 2－3.5 |
#6 |
3.7mm |
6.0 |
16.0 |
6.5 |
| YS 2－4 |
#8 |
4.3mm |
6.4 |
16.0 |
6.5 |
| YM 2－4 |
#8 |
4.3mm |
7.2 |
16.0 |
6.5 |
| YL 2－4 |
#8 |
4.3mm |
8.1 |
16.0 |
6.5 |
| YS 2－5 |
#10 |
5.3mm |
8.1 |
16.0 |
6.5 |
| YL 2－5 |
#10 |
5.3mm |
9.5 |
16.0 |
6.5 |
| YS 2－6 |
1/4 |
6.5mm |
9.5 |
16.0 |
6.5 |
| YL 2－6 |
1/4 |
6.5mm |
12.0 |
22.0 |
11.0 |
Cable size: 2.5～4mm2（A.W.G.14～12) max current:Imax=37A material:purple copper thickness:1.0mm
|
Item No
|
Dimension
|
|
USA screw
|
Screw dia.d2
|
B |
L |
F |
E |
Dφ |
dφ |
| mm |
mm |
mm |
mm |
mm |
mm |
mm |
| Y 3.5～4 |
#8 |
4.3mm |
8.0 |
18.3 |
7.0 |
6.0 |
5.0 |
3.0 |
| Y 3.5～5 |
#10 |
5.3mm |
8.0 |
18.3 |
7.0 |
| Y 3.5～6 |
1/4 |
6.5mm |
12.0 |
21.5 |
12.1 |
Cable size: 4～6mm2（A.W.G.12～10) max current:Imax=48A material:purple copper thickness:1.0mm
|
Item No.
|
DIMENSION |
Color
|
America
Bolt no. |
Dia. of bolt |
B |
L |
F |
H |
Dφ |
| dφ |
mm |
mm |
mm |
mm |
mm |
| RF 5.5-3.5 |
#6 |
3.7mm |
7.2 |
21.4 |
5.9 |
13.5 |
6.7 |
Yellow
|
| RFS 5.5-4 |
#8 |
4.3mm |
7.2 |
21.4 |
5.9 |
| RFL 5.5-4 |
#8 |
4.3mm |
9.5 |
25.5 |
8.3 |
| RF 5.5-5 |
#10 |
5.3mm |
9.5 |
25.5 |
8.3 |
| RF 5.5-6 |
1/4 |
6.5mm |
12.0 |
31.5 |
13.0 |
| RF 5.5-8 |
5/16 |
8.4mm |
15.0 |
33.7 |
13.7 |
| RF 5.5-10 |
3/8 |
10.5mm |
15.0 |
33.7 |
13.7 |
| RF 5.5-12 |
1/2 |
13.0mm |
19.2 |
38.1 |
16.0 |
