RCCN DBS-Type Stainless steel Cable Gland

RCCN DBS-Type Stainless steel Cable Gland


RCCN DBS-Type Stainless steel Cable Gland


RCCN DBS-Type Stainless steel Cable Gland

Thread:Metric/PG/NPT/G(PF)
Material:Brass,nickel plated，
Seal/Oring:TPE/NBR
Certificates:CE,EX,ROHS
Tempe.range:-50°C to +150°C  Protection:IP68。



Item No.

Cable
Range
￠

 Thread
Length
L1		 +Nut Max
platethick		 Joint
Length
L2+L3		 Spanner
SW
A/F		 Std.Pkg.
pcs
M
DBS-M12×1.5-6.5 4-6.5 7 ≦3.5 20 14/14 100PCS
DBS-M16×1.5-6.5 4-6.5 7 ≦3.5 20 18/18
DBS-M16×1.5-8 5-8 7 ≦3.5 20 18/18
DBS-M16×1.5-10 6-10 7 ≦3.5 20 18/18
DBS-M18×1.5-6.5 4-6.5 8 ≦4.5 20 20/20
DBS-M18×1.5-8 5-8 8 ≦4.5 20 20/20
DBS-M18×1.5-10 6-10 8 ≦4.5 20 20/20
DBS-M18×1.5-11 7-11 8 ≦4.5 20 20/20
DBS-M20×1.5-6.5 4-6.5 8 ≦4.5 20 22/22
DBS-M20×1.5-8 5-8 8 ≦4.5 20 22/22
DBS-M20×1.5-10 6-10 8 ≦4.5 20 22/22
DBS-M20×1.5-11 7-11 8 ≦4.5 20 22/22
DBS-M20×1.5-13 9-13 8 ≦4.5 20 22/22
DBS-M22×1.5-6.5 4-6.5 9 ≦4.5 21 24/24
DBS-M22×1.5-8 5-8 9 ≦4.5 21 24/24
DBS-M22×1.5-10 6-10 9 ≦4.5 21 24/24
DBS-M22×1.5-11 7-11 9 ≦4.5 21 24/24
DBS-M22×1.5-13 9-13 9 ≦4.5 21 24/24
DBS-M22×1.5-16 11-16 9 ≦4.5 21 24/24
DBS-M25×1.5-6.5 4-6.5 9 ≦4.5 21 28-30/24 25PCS
DBS-M25×1.5-8 5-8 9 ≦4.5 21 28-30/24
DBS-M25×1.5-10 6-10 9 ≦4.5 21 28-30/24
DBS-M25×1.5-11 7-11 9 ≦4.5 21 28-30/24
DBS-M25×1.5-13 9-13 9 ≦4.5 21 28-30/24
DBS-M25×1.5-16 11-16 9 ≦4.5 21 28-30/24
DBS-M32×1.5-11 7-11 11 ≦5.5 25 36-30/30
DBS-M32×1.5-13 9-13 11 ≦5.5 25 36-30/30
DBS-M32×1.5-16 11-16 11 ≦5.5 25 36-30/30
DBS-M32×1.5-18 14-18 11 ≦5.5 25 36-30/30
DBS-M32×1.5-21 17-21 11 ≦5.5 25 36-30/30
DBS-M40×1.5-16 11-16 11 ≦5.5 25 44-40/40 5PCS
DBS-M40×1.5-18 14-18 11 ≦5.5 25 44-40/40
DBS-M40×1.5-21 17-21 11 ≦5.5 25 44-40/40
DBS-M40×1.5-25 20-25 11 ≦5.5 25 44-40/40
DBS-M40×1.5-30 25-30 11 ≦5.5 25 44-40/40
DBS-M50×1.5-32 27-32 11 ≦5.5 28 54-50/50
DBS-M50×1.5-34 29-34 11 ≦5.5 28 54-50/50
DBS-M50×1.5-36 32-36 11 ≦5.5 28 54-50/50
DBS-M63×1.5-44 40-45 14 ≦5.5 30 68-64/64
PG
DBS-PG7-6.5 4-6.5 7 ≦3.5 20 14/14 100PCS
DBS-PG9-6.5 4-6.5 7 ≦3.5 20 18/18
DBS-PG9-8 5-8 7 ≦3.5 20 18/18
DBS-PG9-10 6-10 7 ≦3.5 20 18/18
DBS-PG11-6.5 4-6.5 8 ≦4.5 20 20/20
DBS-PG11-8 5-8 8 ≦4.5 20 20/20
DBS-PG11-10 6-10 8 ≦4.5 20 20/20
DBS-PG11-11 7-11 8 ≦4.5 20 20/20
DBS-PG13.5-6.5 4-6.5 8 ≦4.5 20 22/22
DBS-PG13.5-8 5-8 8 ≦4.5 20 22/22
DBS-PG13.5-10 6-10 8 ≦4.5 20 22/22
DBS-PG13.5-11 7-11 8 ≦4.5 20 22/22
DBS-PG13.5-13 9-13 8 ≦4.5 20 22/22
DBS-PG16-6.5 4-6.5 9 ≦4.5 21 24/24
DBS-PG16-8 5-8 9 ≦4.5 21 24/24
DBS-PG16-10 6-10 9 ≦4.5 21 24/24
DBS-PG16-11 7-11 9 ≦4.5 21 24/24
DBS-PG16-13 9-13 9 ≦4.5 21 24/24
DBS-PG16-16 11-16 9 ≦4.5 21 24/24
DBS-PG21-11 7-11 11 ≦5.5 25 36-30/30 25PCS
DBS-PG21-13 9-13 11 ≦5.5 25 36-30/30
DBS-PG21-16 11-16 11 ≦5.5 25 36-30/30
DBS-PG21-18 14-18 11 ≦5.5 25 36-30/30
DBS-PG21-21 17-21 11 ≦5.5 25 36-30/30
DBS-PG29-16 11-16 11 ≦5.5 25 44-40/40 5PCS
DBS-PG29-18 14-18 11 ≦5.5 25 44-40/40
DBS-PG29-21 17-21 11 ≦5.5 25 44-40/40
DBS-PG29-25 20-25 11 ≦5.5 25 44-40/40
DBS-PG29-30 25-30 11 ≦5.5 25 44-40/40
DBS-PG36-32 27-32 11 ≦5.5 28 54-50/50
DBS-PG36-34 29-34 11 ≦5.5 28 54-50/50
DBS-PG36-36 32-36 11 ≦5.5 28 54-50/50
DBS-PG48-44 40-45 14 ≦5.5 30 68-64/64
 NPT
DBS-NPT1/4-6.5 4-6.5 7 ≦3.5 20 14/14 100PCS
DBS-NPT3/8-6.5 4-6.5 7 ≦3.5 20 18/18
DBS-NPT3/8-8 5-8 7 ≦3.5 20 18/18
DBS-NPT3/8-10 6-10 7 ≦3.5 20 18/18
DBS-NPT1/2-6.5 4-6.5 8 ≦4.5 20 22/22
DBS-NPT1/2-8 5-8 8 ≦4.5 20 22/22
DBS-NPT1/2-10 6-10 8 ≦4.5 20 22/22
DBS-NPT1/2-11 7-11 8 ≦4.5 20 22/22
DBS-NPT1/2-13 9-13 8 ≦4.5 20 22/22
DBS-NPT3/4-6.5 4-6.5 9 ≦4.5 21 28-30/24 25PCS
DBS-NPT3/4-8 5-8 9 ≦4.5 21 28-30/24
DBS-NPT3/4-10 6-10 9 ≦4.5 21 28-30/24
DBS-NPT3/4-11 7-11 9 ≦4.5 21 28-30/24
DBS-NPT3/4-13 9-13 9 ≦4.5 21 28-30/24
DBS-NPT3/4-16 11-16 9 ≦4.5 21 28-30/24
DBS-NPT1-11 7-11 11 ≦5.5 25 36-30/30
DBS-NPT1-13 9-13 11 ≦5.5 25 36-30/30
DBS-NPT1-16 11-16 11 ≦5.5 25 36-30/30
DBS-NPT1-18 14-18 11 ≦5.5 25 36-30/30
DBS-NPT1-21 17-21 11 ≦5.5 25 36-30/30
DBS-NPT1-1/4-16 11-16 11 ≦5.5 25 44-40/40 5PCS
DBS-NPT1-1/4-18 14-18 11 ≦5.5 25 44-40/40
DBS-NPT1-1/4-21 17-21 11 ≦5.5 25 44-40/40
DBS-NPT1-1/4-25 20-25 11 ≦5.5 25 44-40/40
DBS-NPT1-1/4-30 25-30 11 ≦5.5 25 44-40/40
DBS-NPT1-1/2-32 27-32 11 ≦5.5 28 54-50/50
DBS-NPT1-1/2-34 29-34 11 ≦5.5 28 54-50/50
DBS-NPT1-1/2-36 32-36 11 ≦5.5 28 54-50/50
DBS-NPT2-44 40-45 14 ≦5.5 30 68-64/64
G
DBS-G1/4-6.5 4-6.5 7 ≦3.5 20 14/14 100PCS
DBS-G3/8-6.5 4-6.5 7 ≦3.5 20 18/18
DBS-G3/8-13 5-8 7 ≦3.5 20 18/18
DBS-G3/8-13 6-10 7 ≦3.5 20 18/18
DBS-G1/2-6.5 4-6.5 8 ≦4.5 20 22/22
DBS-G1/2-8 5-8 8 ≦4.5 20 22/22
DBS-G1/2-10 6-10 8 ≦4.5 20 22/22
DBS-G1/2-11 7-11 8 ≦4.5 20 22/22
DBS-G1/2-13 9-13 8 ≦4.5 20 22/22
DBS-G3/4-6.5 4-6.5 9 ≦4.5 21 28-30/24 25PCS
DBS-G3/4-8 5-8 9 ≦4.5 21 28-30/24
DBS-G3/4-10 6-10 9 ≦4.5 21 28-30/24
DBS-G3/4-11 7-11 9 ≦4.5 21 28-30/24
DBS-G3/4-13 9-13 9 ≦4.5 21 28-30/24
DBS-G3/4-16 11-16 9 ≦4.5 21 28-30/24
DBS-G1-11 7-11 11 ≦5.5 25 36-30/30
DBS-G1-13 9-13 11 ≦5.5 25 36-30/30
DBS-G1-16 11-16 11 ≦5.5 25 36-30/30
DBS-G1-18 14-18 11 ≦5.5 25 36-30/30
DBS-G1-21 17-21 11 ≦5.5 25 36-30/30
DBS-G1-1/4-16 11-16 11 ≦5.5 25 44-40/40 5PCS
DBS-G1-1/4-18 14-18 11 ≦5.5 25 44-40/40
DBS-G1-1/4-21 17-21 11 ≦5.5 25 44-40/40
DBS-G1-1/4-25 20-25 11 ≦5.5 25 44-40/40
DBS-G1-1/4-30 25-30 11 ≦5.5 25 44-40/40
DBS-G1-1/2-32 27-32 11 ≦5.5 28 54-50/50
DBS-G1-1/2-34 29-34 11 ≦5.5 28 54-50/50
DBS-G1-1/2-36 32-36 11 ≦5.5 28 54-50/50
DBS-G2-44 40-45 14 ≦5.5 30 68-64/64
