RCCN MGB Nylon Cable Gland
 |
| Thread:Metric Material:A.C.E.F made of Rohs approved NYLON66,B.D made of NBR Certificate:UL/CUL:E348185,CE, SGS,REACH,EX Fireproof:UL94V-2。 Operate temperature:-50°C to 150°C。 Protect class:IP68。 Color:light gray(RAL7035),black(RAL9005) |
| Item No. | Thread | CableRange Φ |
Thread O.D. D1 |
Panel Mounting Hole |
Thread Length L1 |
Spanner size A&F |
|
| Black | White | ||||||
| MGB10-06B | MGB10-06G | M10*1.5 | 2-6 | 10 | 10-10.3 | 8.5 | 18/19 |
| MGB12S-06B | MGB12S-06G | M12*1.5 | 2-6 | 12 | 12-12.3 | 8.5 | 18/19 |
| MGB12-07B | MGB12-07G | M12*1.5 | 3-8 | 12 | 12-12.3 | 8.5 | 18/19 |
| MGB16S-08B | MGB16S-08G | M16*1.5 | 3-8 | 16 | 16-16.3 | 10 | 22/20 |
| MGB16-10B | MGB16-10G | M16*1.5 | 4-10 | 16 | 16-16.3 | 10 | 22/22 |
| MGB18-10B | MGB18-10G | M18*1.5 | 5-10 | 18 | 18-18.3 | 10 | 24/22 |
| MGB20S-12B | MGB20S-12G | M20*1.5 | 5-12.5 | 20 | 20-20.3 | 11 | 33/25 |
| MGB20-14B | MGB20-14G | M20*1.5 | 8.5-14 | 20 | 20-20.3 | 11 | 33/27 |
| MGB25-18B | MGB25-18G | M25*1.5 | 12.5-18 | 25 | 25-25.3 | 11.5 | 33/33 |
| MGB32-25B | MGB32-25G | M32*1.5 | 17-25 | 32 | 32-32.3 | 15 | 41/42 |
| MGB36-25B | MGB36-25G | M36*1.5 | 17-25 | 36 | 36-36.3 | 12 | 45/42 |
| MGB40-32B | MGB40-32G | M40*1.5 | 23-32 | 40 | 40-40.3 | 15 | 50/52 |
| MGB50-40B | MGB50-40G | M50*1.5 | 30-41 | 50 | 50-50.3 | 15 | 62/62 |
| MGB63-46B | MGB63-46G | M63*1.5 | 35-46 | 63 | 63-63.3 | 18 | 75/65 |
| MGB12SL-06B | MGB12SL-06G | M12*1.5 | 2-6 | 12 | 12-12.3 | 15 | 18/19 |
| MGB12L-07B | MGB12L-07G | M12*1.5 | 3-8 | 12 | 12-12.3 | 15 | 18/19 |
| MGB16SL-08B | MGB16SL-08G | M16*1.5 | 3-8 | 16 | 16-16.3 | 15 | 22/20 |
| MGB16L-10B | MGB16L-10G | M16*1.5 | 4-10 | 16 | 16-16.3 | 15 | 22/22 |
| MGB18L-10B | MGB18L-10G | M18*1.5 | 5-10 | 18 | 18-18.3 | 15 | 24/22 |
| MGB20L-14B | MGB20L-14G | M20*1.5 | 8.5-14 | 20 | 20-20.3 | 15 | 33/27 |
| MGB25L-18B | MGB25L-18G | M25*1.5 | 12.5-18 | 25 | 25-25.3 | 15 | 33/33 |
MGBdouble hole
|
double |
Item No |
Thread
|
CableRange Φ |
Thread O.D. D1 |
Panel Mounting Hole |
Thread Length L1 |
Spanner size A&F |
Std.Pkg Pcs |
|
|
Black |
White |
||||||||
| item two holes |
MGB16-H2-04B | MGB16-H2-04G | M16*1.5 | 3-4.1 | 16 | 16-16.3 | 15 | 22/22 | 50PCS |
| MGB20-H2-06B | MGB20-H2-06G | M20*1.5 | 4.3-6.1 | 20 | 20-20.3 | 15 | 27/27 | ||
| MGB25-H2-09B | MGB25-H2-09G | M25*1.5 | 6.4-8.7 | 25 | 25-25.3 | 15 | 33/33 | ||
| PGB9-H2-04B | PGB9-H2-04G | PG9 | 3-4.1 | 15.2 | 15.2-15.8 | 8.2 | 22/19 | ||
| PGB13.5-H2-06B | PGB13.5-H2-06G | PG13.5 | 4.3-6.1 | 20.4 | 20.4-20.7 | 10 | 27/24 | ||
| PGB16-H2-09 | PGB16-H2-09G | PG16 | 6.4-8.7 | 22.5 | 22.5-22.8 | 10.8 | 30/27 | ||
