RCCN DABG Brass Cable Gland

RCCN DABG Brass Cable Gland


RCCN DABG Brass Cable Gland


RCCN DABG Brass Cable Gland

 Hose gland made of brass,
to install corrugat ed conduits by a PA66 clamping
ring to reach cable sealing and strain relief.



Item No. BG
AD

Cable
Range
Φ

Thread
Length
L1
+Nut Max
platethick
Joint
Length
H
Spanner
SW
A/F
Std.Pkg.
pcs
M
DA-M16×1.5-6.5/BG07 7×10 4-6.5 7 ≤3.5 24 20/20 100PCS
DA-M16×1.5-6.5/BG10 10×13 4-6.5 7 ≤3.5 21 22/22
DA-M16×1.5-10/BG10 10×13 6-10 7 ≤3.5 21 22/22
DA-M16×1.5-10/BG12 12×15.8 6-10 7 ≤3.5 21 24/24
DA-M18×1.5-10/BG10 10×13 6-10 7 ≤3.5 24 22/22
DA-M18×1.5-11/BG12 12×15.8 7-11 7 ≤4.5 24 24/24
DA-M20×1.5-10/BG10 10×13 6-10 8 ≤4.5 24 22/22
DA-M20×1.5-11/BG12 12×15.8 7-11 8 ≤4.5 25 24/24
DA-M20×1.5-11/BG15 15×18.5 7-11 8 ≤4.5 25 24/24
DA-M20×1.5-16/BG17 17×21.2 11-16 8 ≤4.5 28 30/30 25PCS
DA-M22×1.5-16/BG17 17×21.2 11-16 8 ≤4.5 29 30/30
DA-M25×1.5-16/BG17 17×21.2 11-16 9 ≤4.5 29 30/30 10PCS
DA-M32×1.5-18/BG23 23×28.5 14-18 11 ≤5.5 35 40/40
DA-M32×1.5-21/BG23 23×28.5 17-21 11 ≤5.5 35 40/40
DA-M40×1.5-25/BG29 29×34.5 20-25 11 ≤5.5 35 50/50
DA-M40×1.5-30/BG29 29×34.5 25-30 11 ≤5.5 35 50/50
DA-M50×1.5-30/BG36 36×42.5 25-30 11 ≤5.5 35 58/58
DA-M50×1.5-34/BG36 36×42.5 29-34 11 ≤5.5 35 58/58
DA-M63×1.5-45/BG48 48×54.5 40-45 15 ≤9 40 68-64/64
 PG
DA-PG9-6.5/BG07 7×10 4-6.5 7 ≤3.5 24 20/20 100PCS
DA-PG9-6.5/BG10 10×13 4-6.5 7 ≤3.5 21 22/22
DA-PG9-10/BG10 10×13 6-10 7 ≤3.5 21 22/22
DA-PG9-10/BG12 12×15.8 6-10 7 ≤3.5 21 24/24
DA-PG11-10/BG10 10×13 6-10 7 ≤3.5 24 22/22
DA-PG11-11/BG12 12×15.8 7-11 7 ≤4.5 24 24/24
DA-PG13.5-10/BG10 10×13 6-10 8 ≤4.5 24 22/22
DA-PG13.5-11/BG12 12×15.8 7-11 8 ≤4.5 25 24/24
DA-PG13.5-11/BG15 15×18.5 7-11 8 ≤4.5 25 24/24
DA-PG13.5-16/BG17 17×21.2 11-16 8 ≤4.5 28 30/30 25PCS
DA-PG16-16/BG17 17×21.2 11-16 8 ≤4.5 29 30/30
DA-PG21-18/BG23 23×28.5 14-18 11 ≤5.5 35 40/40 10PCS
DA-PG21-21/BG23 23×28.5 17-21 11 ≤5.5 35 40/40
DA-PG29-25/BG29 29×34.5 20-25 11 ≤5.5 35 50/50
DA-PG29-30/BG29 29×34.5 25-30 11 ≤5.5 35 50/50
DA-PG36-30/BG36 36×42.5 25-30 11 ≤5.5 35 58/58
DA-PG36-34/BG36 36×42.5 29-34 11 ≤5.5 35 58/58
DA-PG48-45/BG48 48×54.5 40-45 15 ≤9 40 68-64/64
 NPT
DA-NPT3/8-6.5/BG07 7×10 4-6.5 7 ≤3.5 24 20/20 100PCS
DA-NPT3/8-6.5/BG10 10×13 4-6.5 7 ≤3.5 21 22/22
DA-NPT3/8-10/BG10 10×13 6-10 7 ≤3.5 21 22/22
DA-NPT3/8-10/BG12 12×15.8 6-10 7 ≤3.5 21 24/24
DA-NPT1/2-10/BG10 10×13 6-10 8 ≤4.5 24 22/22
DA-NPT1/2-11/BG12 12×15.8 7-11 8 ≤4.5 25 24/24
DA-NPT1/2-11/BG15 15×18.5 7-11 8 ≤4.5 25 24/24
DA-NPT1/2-16/BG17 17×21.2 11-16 8 ≤4.5 28 30/30 25PCS
DA-NPT3/4-16/BG17 17×21.2 11-16 9 ≤4.5 29 30/30
DA-NPT1-18/BG23 23×28.5 14-18 11 ≤5.5 35 40/40 10PCS
DA-NPT1-21/BG23 23×28.5 17-21 11 ≤5.5 35 40/40
DA-NPT1-1/4-25/BG29 29×34.5 20-25 11 ≤5.5 35 50/50
DA-NPT1-1/4-30/BG29 29×34.5 25-30 11 ≤5.5 35 50/50
DA-NPT1-1/2-30/BG36 36×42.5 25-30 11 ≤5.5 35 58/58
DA-NPT1-1/2-34/BG36 36×42.5 29-34 11 ≤5.5 35 58/58
DA-NPT2-45/BG48 48×54.5 40-45 15 ≤9 40 68-64/64
G
DA-G3/8-6.5/BG07 7×10 4-6.5 7 ≤3.5 24 20/20 100PCS
DA-G3/8-6.5/BG10 10×13 4-6.5 7 ≤3.5 21 22/22
DA-G3/8-10/BG10 10×13 6-10 7 ≤3.5 21 22/22
DA-G3/8-10/BG12 12×15.8 6-10 7 ≤3.5 21 24/24
DA-G1/2-10/BG10 10×13 6-10 8 ≤4.5 24 22/22
DA-G1/2-11/BG12 12×15.8 7-11 8 ≤4.5 25 24/24
DA-G1/2-11/BG15 15×18.5 7-11 8 ≤4.5 25 24/24
DA-G1/2-16/BG17 17×21.2 11-16 8 ≤4.5 28 30/30 25PCS
DA-G3/4-16/BG17 17×21.2 11-16 9 ≤4.5 29 30/30
DA-G1-18/BG23 23×28.5 14-18 11 ≤5.5 35 40/40 10PCS
DA-G1-21/BG23 23×28.5 17-21 11 ≤5.5 35 40/40
DA-G1-1/4-25/BG29 29×34.5 20-25 11 ≤5.5 35 50/50
DA-G1-1/4-30/BG29 29×34.5 25-30 11 ≤5.5 35 50/50
DA-G1-1/2-30/BG36 36×42.5 25-30 11 ≤5.5 35 58/58
DA-G1-1/2-34/BG36 36×42.5 29-34 11 ≤5.5 35 58/58
DA-G2-45/BG48 48×54.5 40-45 15 ≤9 40 68-64/64
