RCCN SVD Hose Steel Braid Cable Gland
 |
|
|
| Item No. | Thread Length L1 |
hose clamps Φ |
+Nut Max platethick |
Joint Length H |
Spanner SW A/F |
Std.Pkg. pcs |
|
M
|
||||||
| SVD-M12×1.5-12 | 6 | 10-12 | ≦2.5 | 20 | 18/18 | 100PCS |
| SVD-M16×1.5-15 | 7 | 13-15 | ≦3.5 | 21 | 20/20 | |
| SVD-M16×1.5-17 | 7 | 14-17 | ≦3.5 | 21 | 22/22 | |
| SVD-M18×1.5-15 | 7 | 13-15 | ≦3.5 | 21 | 20/20 | |
| SVD-M18×1.5-17 | 7 | 14-17 | ≦3.5 | 21 | 22/22 | |
| SVD-M18×1.5-18 | 7 | 15-18 | ≦3.5 | 21 | 24/24 | |
| SVD-M20×1.5-17 | 8 | 14-17 | ≦4.5 | 21 | 22/22 | |
| SVD-M20×1.5-18 | 8 | 15-18 | ≦4.5 | 21 | 24/24 | |
| SVD-M20×1.5-22 | 8 | 18-22 | ≦4.5 | 23 | 28/28 | 50PCS |
| SVD-M20×1.5-23 | 8 | 19-23 | ≦4.5 | 23 | 30/30 | |
| SVD-M22×1.5-23 | 8 | 19-23 | ≦4.5 | 24 | 30/30 | |
| SVD-M25×1.5-23 | 9 | 19-23 | ≦4.5 | 24 | 30/30 | 10PCS |
| SVD-M32×1.5-29 | 11 | 24-29 | ≦5.5 | 26 | 36/36 | |
| SVD-M36×2.0-32 | 11 | 28-32 | ≦5.5 | 26 | 40/40 | |
| SVD-M40×1.5-36 | 11 | 31-36 | ≦5.5 | 26 | 44/44 | |
| SVD-M40×1.5-40 | 11 | 34-40 | ≦5.5 | 27 | 50/50 | |
| SVD-M50×1.5-46 | 11 | 40-46 | ≦5.5 | 29 | 58/58 | |
| SVD-M63×1.5-56 | 14 | 50-56 | ≦9 | 30 | 68/68 | |
|
PG
|
||||||
| SVD-PG7-12 | 6 | 10-12 | ≦2.5 | 20 | 18/18 | 100PCS |
| SVD-PG9-15 | 7 | 13-15 | ≦3.5 | 21 | 20/20 | |
| SVD-PG9-17 | 7 | 14-17 | ≦3.5 | 21 | 22/22 | |
| SVD-PG11-15 | 7 | 13-15 | ≦3.5 | 21 | 20/20 | |
| SVD-PG11-17 | 7 | 14-17 | ≦3.5 | 21 | 22/22 | |
| SVD-PG11-18 | 7 | 15-18 | ≦3.5 | 21 | 24/24 | |
| SVD-PG13.5-17 | 8 | 14-17 | ≦4.5 | 21 | 22/22 | |
| SVD-PG13.5-18 | 8 | 15-18 | ≦4.5 | 21 | 24/24 | |
| SVD-PG13.5-22 | 8 | 18-22 | ≦4.5 | 23 | 28/28 | 50PCS |
| SVD-PG13.5-23 | 8 | 19-23 | ≦4.5 | 23 | 30/30 | |
| SVD-PG16-23 | 8 | 19-23 | ≦4.5 | 24 | 30/30 | |
| SVD-PG21-23 | 9 | 19-23 | ≦4.5 | 24 | 30/30 | 10PCS |
| SVD-PG21-29 | 11 | 24-29 | ≦5.5 | 26 | 36/36 | |
| SVD-PG21-32 | 11 | 28-32 | ≦5.5 | 26 | 40/40 | |
| SVD-PG29-36 | 11 | 31-36 | ≦5.5 | 26 | 44/44 | |
| SVD-PG29-40 | 11 | 34-40 | ≦5.5 | 27 | 50/50 | |
| SVD-PG36-46 | 11 | 40-46 | ≦5.5 | 29 | 58/58 | |
| SVD-PG48-56 | 14 | 50-56 | ≦9 | 30 | 68/68 | |
|
NPT
|
||||||
| SVD-NPT1/4-12 | 6 | 10-12 | ≦2.5 | 20 | 18/18 | 100PCS |
| SVD-NPT3/8-15 | 7 | 13-15 | ≦3.5 | 21 | 20/20 | |
| SVD-NPT3/8-17 | 7 | 14-17 | ≦3.5 | 21 | 22/22 | |
| SVD-NPT1/2-17 | 8 | 14-17 | ≦4.5 | 21 | 22/22 | |
| SVD-NPT1/2-18 | 8 | 15-18 | ≦4.5 | 21 | 24/24 | |
| SVD-NPT1/2-22 | 8 | 18-22 | ≦4.5 | 23 | 28/28 | 50PCS |
| SVD-NPT1/2-23 | 8 | 19-23 | ≦4.5 | 23 | 30/30 | |
| SVD-NPT3/4-23 | 9 | 19-23 | ≦4.5 | 24 | 30/30 | 10PCS |
| SVD-NPT1-29 | 11 | 24-29 | ≦5.5 | 26 | 36/36 | |
| SVD-NPT1-1/4-36 | 11 | 31-36 | ≦5.5 | 26 | 44/44 | |
| SVD-NPT1-1/4-40 | 11 | 34-40 | ≦5.5 | 27 | 50/50 | |
| SVD-NPT1-1/2-46 | 11 | 40-46 | ≦5.5 | 29 | 58/58 | |
| SVD-NPT2-56 | 14 | 50-56 | ≦9 | 30 | 68/68 | |
|
G
|
||||||
| SVD-G1/4-12 | 6 | 10-12 | ≦2.5 | 20 | 18/18 | 100PCS |
| SVD-G3/8-15 | 7 | 13-15 | ≦3.5 | 21 | 20/20 | |
| SVD-G3/8-17 | 7 | 14-17 | ≦3.5 | 21 | 22/22 | |
| SVD-G1/2-17 | 8 | 14-17 | ≦4.5 | 21 | 22/22 | |
| SVD-G1/2-18 | 8 | 15-18 | ≦4.5 | 21 | 24/24 | |
| SVD-G1/2-22 | 8 | 18-22 | ≦4.5 | 23 | 28/28 | 50PCS |
| SVD-G1/2-23 | 8 | 19-23 | ≦4.5 | 23 | 30/30 | |
| SVD-G3/4-23 | 9 | 19-23 | ≦4.5 | 24 | 30/30 | 10PCS |
| SVD-G1-29 | 11 | 24-29 | ≦5.5 | 26 | 36/36 | |
| SVD-G1-1/4-36 | 11 | 31-36 | ≦5.5 | 26 | 44/44 | |
| SVD-G1-1/4-40 | 11 | 34-40 | ≦5.5 | 27 | 50/50 | |
| SVD-G1-1/2-46 | 11 | 40-46 | ≦5.5 | 29 | 58/58 | |
| SVD-G2-56 | 14 | 50-56 | ≦9 | 30 | 68/68 | |
