RCCN SPK Cable Gland
  |
| Material:A.C.F are made of zinc metel coated nickel.D is ande of metal.B.E are made of NBR Protect:IP54。 The items can be made in round outside, part no. like:SPK-M20/R SPK, JIS and PJ are thin connectors |
|
|
Thread |
CableRange |
Thread |
Panel |
Thread |
Joint |
Spanner |
Std.Pkg |
|
Germany thread
|
100PCS | |||||||
| SPK-PG-7 | PG-7 | 6-8 | 12.5 | 12.5-12.8 | 5 | 15 | 15 | |
| SPK-PG-9 | PG-9 | 6-8 | 15.2 | 15.2-15.8 | 6 | 17 | 17 | |
| SPK-PG-9 | PG-9 | 8-10 | 15.2 | 15.2-15.8 | 6 | 17 | 17 | |
| SPK-PG-11 | PG-11 | 6-8 | 18.6 | 18.6-18.9 | 6 | 17 | 20 | |
| SPK-PG-11 | PG-11 | 8-10 | 18.6 | 18.6-18.9 | 6 | 17 | 20 | |
| SPK-PG-11 | PG-11 | 10-12 | 18.6 | 18.6-18.9 | 6 | 18 | 20 | |
| SPK-PG-13.5 | PG-13.5 | 12-14 | 20.4 | 20.4-20.7 | 7 | 19.5 | 24 | |
|
Thread length
|
100PCS | |||||||
| SPK-M12*1.5 | M12*1.5 | 6-8 | 12 | M12*1.5 | 5 | 15 | 15 | |
| SPK-M16S*1.5 | M16*1.5 | 6-8 | 16 | M16*1.5 | 6 | 17 | 17 | |
| SPK-M16*1.5 | M16*1.5 | 8-10 | 16 | M16*1.5 | 6 | 17 | 17 | |
| SPK-M18S*1.5 | M18*1.5 | 6-8 | 18 | M18*1.5 | 6 | 17 | 20 | |
| SPK-M18*1.5 | M18*1.5 | 8-10 | 18 | M18*1.5 | 6 | 17 | 20 | |
| SPK-M18D*1.5 | M18*1.5 | 10-12 | 18 | M18*1.5 | 6 | 18 | 20 | |
| SPK-M20*1.5 | M20*1.5 | 12-14 | 20 | M20*1.5 | 7 | 19.5 | 24 | |
| SPK-M25*1.5 | M25*1.5 | 14-18 | 25 | M25*1.5 | 7 | 32.5 | 30/34 | |
| SPK-M32*1.5 | M32*1.5 | 17-23 | 32 | M32*1.5 | 8 | 32.5 | 36/40 | 20PCS |
| SPK-M36*1.5 | M36*1.5 | 22-27 | 36 | M36*1.5 | 8 | 35 | 45/48 | |
| SPK-M40*1.5 | M40*1.5 | 26-33 | 40 | M40*1.5 | 9 | 35 | 50/55 | 5PCS |
| SPK-M50*1.5 | M50*1.5 | 32-41 | 50 | M50*1.5 | 9 | 37 | 58/65 | |
| SPK-M56*2.0 | M56*1.5 | 40-49 | 56 | M56*1.5 | 9 | 40 | 65/70 | |
| SPK-M63*1.5 | M63*1.5 | 48-57 | 63 | M63*1.5 | 10 | 40 | 75/80 | |
