产品信息:
087-1 RCCN 日成电源线扣
STRAIN RELIEF BUSHING
![[m0705]](huxiantao/dian yuan xian kou -1.jpg)
![[s0705-4]](images/s0705-4.jpg) ![[sc0705-6]](images/sc0705-6.jpg)
![[sc0705-5]](images/sc0705-5.jpg)
  |
|
单位 : mm
- 型号
Cross Section
- Item No.
|
- 型状
shape
|
- 适用电线
- Wires Accomodated
|
- 铁板孔径
- Mounting Hole
|
- 线扣
长度
- Part L.
D.
|
- 适用
机板厚度
- Max. Chassis
Thickness
F.
|
- 包装
- Packing
|
| U.L 线 |
尺寸 |
A |
B |
| SR-F21 |
扁型
Flat |
SPT-1 |
2.3X4.5 |
9.5 |
8.7 |
10.3 |
0.5-1.6 |
- 每包100pcs
(1000pcs)
|
| 2.8X5.3 |
| SR-F23 |
SPT-1 |
2.3X4.5 |
9.5 |
8.7 |
10.3 |
1.8-3.2 |
| 2.8X5.3 |
| SR-F31 |
SPT-1 |
3.0X5.6 |
11.0 |
9.9 |
10.3 |
1.0-1.6 |
| SR-F32 |
SPT-1 |
3.0X5.6 |
11.0 |
9.9 |
10.3 |
1.9-2.5 |
| SR-F41 |
SPT-2 |
3.0X7.1 |
12.7 |
11.8 |
10.3 |
0.5-1.6 |
| 3.8X7.6 |
| SR-F42 |
SPT-2 |
3.0X7.1 |
12.7 |
11.8 |
10.3 |
1.8-2.5 |
| 3.8X7.6 |
| SR-F51 |
SPT-3 |
5X10.4 |
14.3 |
13.2 |
15.2 |
0.5-1.6 |
| SR-F53 |
SPT-3 |
5X10.4 |
14.3 |
13.2 |
15.2 |
1.8-3.5 |
| SR-F83 |
圆型
Round |
Alt Condition Wire 3C 2mm2 |
6X13 |
21.6 |
21.3 |
20.4 |
2.0-3.4 |
| SR-5R1 |
SVI,SVT |
6.2ø ~7.4ø |
12.7 |
11.5 |
11.0 |
0.5-1.6 |
| SR-5R2 |
SVI,SVT |
6.2ø ~7.4ø |
12.7 |
11.5 |
11.0 |
1.8-2.5 |
| SR-6W2 |
SVI |
7.6ø |
12.7 |
11.8 |
11.0 |
1.8-2.3 |
| SR-6P1 |
SJC 3C # 18 |
7.4ø~8.2ø |
15.9 |
14.0 |
14.8 |
0.5-1.6 |
| SR-6P3 |
SJC 3C # 18 |
7.4ø~8.2ø |
15.9 |
14.0 |
14.8 |
1.9-3.2 |
| SR-6R1 |
SJ,SJT,3C # 16 |
8.2ø~9.2ø |
15.9 |
14.0 |
14.8 |
0.5-1.6 |
| SR-6R3 |
SJ,SJT,3C # 16 |
8.2ø~9.2ø |
15.9 |
14.0 |
14.8 |
1.9-3.2 |
| SR-7R1 |
SJT,3C # 14 |
9.2ø~10.5ø |
19.0/19.8 |
16.5 |
19.0 |
0.5-1.6 |
| 11ø |
| SR-7R3 |
SJT,3C # 14 |
9.2ø~10.5ø |
19.0/19.8 |
16.5 |
19.0 |
1.9-3.2 |
| 11ø |
| SR-8R3 |
SJT,3C # 12 |
12ø~15.2ø |
22.2 |
21.3 |
20.6 |
1.9-3.2 |
| SR-9R1 |
电源供应器专用. |
# 18 20-30pcs |
11ø~15ø |
20 |
19 |
17.5 |
0.5-1.6 |
| SR-9R7 |
SJT,3C # 10 |
15.2ø~16.3ø |
28.0/30.2 |
25.5 |
25.2 |
1.0-3.2 |
| 17.5ø |
