Thread:G,Metric, PG
Material:A.C.F are made from zincic metal.B.E are made of
NBR.D is made of iron sheet .
Certificates:CE RoHS
Color:Argentine(silver)
Protect class:IP6
Operate T.:-40°C to 100°C,120°C in a short time.
Features: 1.90°between items and box after joining,thickness
added zinc coated metal
2.special thread can be produced

ܵ઄໕ NBG-G
NBW-04G G3/8" MCR-04 13 16.66 3/8" 8 50 30
NBW-05G G1/2" MCR-05 16 20.95 1/2" 11 54 30
NBW-06G G3/4" MCR-06 20 26.44 3/4" 14 60 30
NBW-08G G1" MCR-08 25 33.25 1" 15 70 20
NBW-10G G1 1/4" MCR-10 32 1 1/4" 42.91 15 90 20
NBW-12G G1 1/2" MCR-12 38 1 1/2 47.8 16 100 20
NBW-16G G2" MCR-16 51 59.6 2"18 120 10
NBW-20G G2 1/2" MCR-20 64 2 1/2" 75.18 22 160 10
NBW-24G G3" MCR-24 80 3" 87.88 22 190 5
NBW-32G G4" MCR-32 100 4" 113 24 220 5
܄ᇅ઄໕ NBG-M
NBW-04M M16*1.5 MCR-04 13 3/8" 8 50 30
16
NBW-05M M20*1.5 MCR-05 16 1/2"20 11 54 30
NBW-06M M25*1.5 MCR-06 20 3/4"25 14 60 30
NBW-08M M32*1.5 MCR-08 25 32 15 70 20
1"
NBW-10M M40*1.5 MCR-10 32 1 1/4" 40 15 90 20
NBW-12M M50*1.5 MCR-12 38 1 1/2 50 16 100 20
NBW-16M M63*1.5 MCR-16 51 63 2"18 120 10
֣ᇅ઄໕ NBG-PG
NBW-04P PG11 MCR-04 13 18.6 3/8" 8 50 30
NBW-05P PG13.5 MCR-05 16 20.4 1/2"11 54 30
NBW-06P PG21 MCR-06 20 28.3 3/4" 14 60 30
NBW-08P PG29 MCR-08 25 37.0 1" 15 70 20
NBW-10P PG29 MCR-10 32 1 1/4" 37.0 15 90 20
NBW-12P PG36 MCR-12 38 1 1/2 47.0 16 100 20
2"
NBW-16P PG48 MCR-16 51 59.3 18 120 10
